Clock Divider
Post new topic   Reply to topic Moderators: Scott Stites
Page 1 of 1 [2 Posts]
View unread posts
View new posts in the last week
Mark the topic unread :: View previous topic :: View next topic
Author Message
AlanP



Joined: Mar 11, 2014
Posts: 93
Location: New Zealand
Audio files: 3

PostPosted: Thu Apr 23, 2015 12:15 am    Post subject: Clock Divider Reply with quote  Mark this post and the followings unread

Soldered up a Yusynth Clock Divider! It takes the incoming clock and divides it down, either by two, or three, all the way to dividing by eight. Yves Usson's page is a lot better at describing this: http://www.yusynth.net/Modular/EN/DIVIDER/index.html

But if you looked at the wiring diagram on his page, there is a lot of wires. I hate doing wires. So I fired up Eagle. Yes, those rotary switches come in 1P8T as well as 2P4T. The 1P8T cost a lot and only come from Mouser, though.

Posted Image, might have been reduced in size. Click Image to view fullscreen.
Posted Image, might have been reduced in size. Click Image to view fullscreen.
Posted Image, might have been reduced in size. Click Image to view fullscreen.

This one was a complete SWINE to lay out. And I got the rotary switch layout wrong (which is why the jack board is a newer revision than the engine board.) But it is now working! (I had the LEDs sitting loose in the holes for them -- I plan on soldering them in when I get a faceplate made and can do the right length for them that way.)

Yves, I'd like to thank you again for all your wonderful, wonderful projects. They always work, and are always marvellous!
