A short while ago I designed a mechanical inverter based on this design:

http://www.thingiverse.com/thing:773

and it got me thinking of mechanical circuits. I guess things percolated to today, seeking for something fun to create, and it occurred that sequencers could be made using age-old mechanical circuit techniques.

So I brought it up in chat and we thought up some possibilities. So that is the purpose of this thread! We know the appeal electro-music is largely the modern usage of time-honored techniques, so why not explore the territory of electro-mechanical-music! That could be equally appealing! Plus fun! Let's discuss the topic...

Les

Inventor · Posted: Wed Nov 16, 2016 3:11 pm Post subject:

Here is the mechanical inverter that I mentioned. the input is determined to be on one corner and the inversion is on the diagonally opposite corner. the value is encoded as right or left.

This model is kinda stiff and high friction, mostly because there is not shaft on the gear (i was modeling what the original design did, to be improved later). also the teeth are just trapezoids IIRC, and not properly shaped gear teeth. So I gotta redo it.

Anyway, it is basically a rack and pinion with an extra rack i suppose you could say. you'll notice my knowledge of mechanical things is rather limited, making this fun if not efficient exploration.

Also pictured is a decorative frame that I was going to use as a cell phone cover. now I am thinking that a better use for it is as a decorative encasement for such mechanical circuits. And in 3D not just the 2.5D (as they call it) shown.

Les

mechanical inverter.JPG

Description:

mechanical inverter and decorative frame

Filesize:

1.5 MB

Viewed:

632 Time(s)

This image has been reduced to fit the page. Click on it to enlarge.

Antimon · Posted: Thu Nov 17, 2016 2:49 am Post subject:

Nice! I've been thinking myself about stuff you could do with a 3d printer to make mechanical noise.

Fun note: I read your subtitle as "making modem music the old fashioned way", i.e. "modem" instead of "modern"! Very Happy

Inventor · Posted: Thu Nov 17, 2016 1:45 pm Post subject:

modem music sounds cool. the mechanical music, well i made a gear try at it and it was not very successful. the gears did turn but only with a lot of friction, plus i knew the design would not reduce the speed at each gear stage but i printed it anyway to check for fit and the use of the big nozzle on the little gears and to see that it all printed properly and quickly.

It was not a very successful print, so I decided to punt!

Some days you gotta punt!

Try, try, another day!

Les
