Electro-Music Klee Sequencer Build and Applications Thread

[etaoin]

Second Klee hits Holland.

---

Description:
Filesize:	261.76 KB
Viewed:	335 Time(s)
This image has been reduced to fit the page. Click on it to enlarge.

---

[State Machine]

[fonik]

finally the zollamt decided to pass it on.

klee unleashed in germany:

---

Description:
Filesize:	143.25 KB
Viewed:	9250 Time(s)

---

[Scott Stites]

Wow - welcome news about Ray's trigger/gate levels. I was all primed to say oh, no-no-no, but I see his new ADSR board does react to >2V.

The reason? I built a version of Ray's ADSR with the state indicating LEDs (and also, his original AR version) - if you look at those designs, he indicates 0 to +12V, though, IIRC, 10V seemed to work fine.

The reason I say "IIRC" is that, because they wouldn't trigger off of my Thomas Henry +5V Gate/Trigger, I outfitted each EG with a comparator that would pomp-op the volume on the gate/trigger signals so they worked with everything in my system. So - if your Ray Wilson EGs are the old style, 5V won't trigger/gate.

BTW, Music From Outer Space has my vote for the most entertaining/informative SDIY site there is. Ray is king.

Thanks for checking the PAiA Bill!

Cheers,
Scott

[Scott Stites]

Sneak Klee Drive Through Belgium Shocks Germany! Australia Folds!

Klee Klique Klaims Kurrent Kartography Kaput; EU Now KU; USA now USK; UK Now UK, Only Different; Australia Now Kleestralia; Kaos Ensues in Kleenada, Particularly Kleebec

[Rykhaard]

[EdisonRex]

Here's hoping anything shows up... sigh.

[etaoin]

Build manual page 75 and 76, the list of 100k resistors is the same as the list of 6k8 resistors...

6k8 list should probably be R32-R47.

[Scott Stites]

Thank you, Etaoin. Looks like that error also affects Appendix B, Page B1.

I'll post the individual page corrections as well as Issue 3.

Hope that didn't jack anybody up

I'm going to put links to all of the current docs in the first post of this thread. That'll create a common place for everyone to be sure they have the latest version.

If anyone else happens across anything like this, please post here or PM me, and I'll correct things as they're brought to my attention.

Cheers,
Scott

[fonik]

[Scott Stites]

Here is Build Issue 3, which corrects the 6K8 reference designator error Etaoin pointed out. The corrected pages are also posted here - if you've already printed Build Issue 2, you can replace the erroneous pages with these pages.

I'm now going to work on Post 1 of this thread and create a place you can find all of the links to all of the docs people don't have to skim the thread looking for it all.

Thanks again, Etaoin. That's a biggee.

Edit: Don't Download Issue 3 - Issue 4 will cover some more issues here shortly.

Deleted balloxed Issue 3. Issue 4 posted later in thread. Post 1 of the thread provides link as well.



Cheers,
Scott

---

Corrected_issue2_page76.pdf
Description:	Corrected Page 76 of Issue 2 Build Doc.	Download (listen)
Filename:	Corrected_issue2_page76.pdf
Filesize:	6.18 KB
Downloaded:	1596 Time(s)

---

---

Corrected_issue2_AppendixB_pageB1.pdf
Description:	Corrected page B1 of Issue 2 Build Doc.	Download (listen)
Filename:	Corrected_issue2_AppendixB_pageB1.pdf
Filesize:	5.81 KB
Downloaded:	1584 Time(s)

---

[Scott Stites]

Links to all the docs are now and will always be available in the first post of this thread.

Cheers,
Scott

[etaoin]

Spotted another one. Page 78, U1 and U8. it says LM358 in the list but LM356 in the placement guide.

[Scott Stites]

Thanks again, and might I add - aaaarrrggghhh

[etaoin]

Page 87, R29 is missing from the list.

[RF]

New title for this thread....
"In which Scott S. Says "DOh!""





Hang in there Scott...

[etaoin]

Last one for today; P89, R34-R41 are actually 7 or 8 trimmers, (doc says 5 or 6).

[Scott Stites]

[Scott Stites]

[Scott Stites]

For the day?

[abis]

[a.b.o.z.]

woohooo
made it just in time
klee is on it's way to croatia
jupi jei
kleeatia
cheers

[Scott Stites]

Issue 3 was too hastily issued, and the formatting on a few pages got screwed up as well. After Issue 3 was put out, Etaoin uncovered some more issues.

I'll write up a decent errata (erotica?) sheet between issues 2 and 4, with mention that issue 3 was just tossed. In the meantime, these additional pages will correct issue 2.

These pages cover the missing R29 in the build section and Appendix A, the erroneous depiction of an LM356 instead of LM358 on the IC placement illustration, and the miscount of the number of 10K trimpots on the Analog Board.


Issue 4 incorporates all of the corrections to Issue 2.

Sorry to all and thank you Etaoin for spotting and pointing out the mistakes. If any others pop up, please let me know.

Cheers,
Scott

---

Corrected_issue2_page88_thru_89.pdf
Description:	Replace Issue 2 pages 88 and 89 with this. Corrects deletion of R29 and miscount of 10K trimpots in analog board build section.	Download (listen)
Filename:	Corrected_issue2_page88_thru_89.pdf
Filesize:	8.38 KB
Downloaded:	2642 Time(s)

---

---

Corrected_issue2_page78.pdf
Description:	Replace page 78 of Issue 2 build doc with this. Displays LM358 instead of LM356 in IC placement guide.	Download (listen)
Filename:	Corrected_issue2_page78.pdf
Filesize:	39.29 KB
Downloaded:	1683 Time(s)

---

---

Corrected_1ssue_2_AppendA_pageA1.pdf
Description:	Replace Issue 2 page A1 with this. Mentions missing R29 of Analog Board in BOM.	Download (listen)
Filename:	Corrected_1ssue_2_AppendA_pageA1.pdf
Filesize:	6.47 KB
Downloaded:	1291 Time(s)

---

---

em_klee_build_issue4.pdf
Description:	Issue 4 of Build Doc. Incorporates all fixes from Issue 2. Get rid of Issue 3 if you have it.	Download (listen)
Filename:	em_klee_build_issue4.pdf
Filesize:	2.51 MB
Downloaded:	5275 Time(s)

---
